Our products

B- Line

Article No. Model Internal Dimension [LxWxH cm] Gross Weight [kg] Payload [kg] Loading Height [cm] Tyres [Inches]
1417500 B7520D 207 X 118 X 37 750 555 55 13
14127500 B7520HD 207 X 118 X 37 750 522 55 13
1425750 B752413D 250 X 118 X 37 750 528 55 13
14225750 B752413HD 250 X 118 X 37 750 512 55 13
1431300 B1326HD 264 X 135 X 37 1300 965 55 13
1441300 B1330HD 308 X 150 X 37 1300 954 55 13
1452000 B2030HTD 308 X 150 X 37 2000 1579 55 13
1462700 B2730HTD 308 X 150 X 37 2700 2269 55 13
Article No. Name Remark
117519 Support stands 2 pieces
147753_* Flat tarpaulin

B7520D B7520D B1326D B2030HD
141753_* Tarpaulin H 93 cm B7520D
142753_* Tarpaulin H 123 cm B7520HD
143753_* Tarpaulin H 123 cm B752413D
144753_* Tarpaulin H 123 cm B1326D
145753_* Tarpaulin H 123 cm B1330HD
146753_* Tarpaulin H 123 cm B2030HTD
demo
demo
demo
demo
demo
demo
demo
demo

Standard equipment:

  • Steel frame welded, hot dipped galvanised
  • V-shaped drawbar
  • Ball coupling
  • Multiplex-wood floor, Lashing rings integrated in floor plate
  • Wood broadside
  • Rubber spring axle AL-KO or KNOTT
  • shock absorbers
  • H-frame ahead
  • Railing sides
  • 100 km/h -approval
  • Jockey wheel
  • 13-pin plug
