BE Line

Article No. Model Internal Dimension [LxWxH cm] Gross Weight [kg] Payload [kg] Loading Height [cm] Tyres [Inches]
01201017561 BE7515U 150 X 100 X 39 750 608 53 13
01202017561 BE751712 170 X 122 X 39 750 605 53 13
01203017561 BE7520U 205 X 122 X 39 750 598 53 13
01204017561 BE7523U 233 X 132 X 39 750 576 53 13
01205017561 BE7523T 233 X 132 X 39 750 558 53 13
01206017561 BE752412U 243 X 121 X 39 750 560 53 13
01207017561 BE732413U 243 X 133 x 39 750 550 53 13
01208017561 BE7526U 265 X 126 x 39 750 560 53 13
01209017561 BE752412T 243 X 121 X 39 750 520 53 13
01210017561 BE752413T 243 X 133 x 39 750 510 53 13
01211017561 BE752612T 265 X 126 x 39 750 530 53 13



Article No. Name Remark
117510 Jockey wheel with assembly parts
117519 Support stands  2 pieces
151752 _* Flat tarpaulin

7515U
1522752_* Flat tarpaulin 7517U
153752 _*  Flat tarpaulin 7520U
154752 _* Flat tarpaulin 7523U
151753 _* Tarpaulin LH 80 cm BE 7520U
152753 _* Tarpaulin LH 120 cm BE 7520U
153753 _* Tarpaulin LH 80 cm BE 7523U+T
154753 _* Tarpaulin LH 120 cm BE 7523U
155753 _* Tarpaulin LH 120 cm BE 752412U
156753 _* Tarpaulin LH 120 cm BE 752413U
15775 _* Tarpaulin LH 120 cm BE 7526U
1517540 Broadside extension H 39 cm BE 7515U
1527540 Broadside extension H 39 cm BE 7517U
1537540 Broadside extension H 39 cm BE 7520U
1547540 Broadside extension H 39 cm BE 7523U+T
1557540 Broadside extension H 39 cm BE 752412U+T
1567540 Broadside extension H 39 cm BE 752413U+T
1577540 Broadside extension H 39 cm BE 7526U+T
1587540 Mesh H 35 cm BE 7517U
1597540 Mesh H 35 cm BE 7523U
1607540 Mesh H 35 cm BE 752412U+T
1617540 Mesh H 35 cm BE 752413U+T



demo
demo

Standard equipment:

  • Steel frame screwed, hot dipped galvanised
  • V shaped drawbar
  • Floor plate 9 mm thick
  • Lashing rings integrated in floor plate
  • Broadside made of galvanised steel
  • Flap ahead
  • 7 –pin plug
  • Preassembled knobs for tarpaulin
